Flexible Power Drops
Effectively distribute power above your facility for easy modifications and expansions that require little-to-no downtime.
Accessible Overhead Power:
Unlike a traditional pipe-and-wire system, this USA TrackBusway™includes a continuous access slot to tap power at any point along the USA TrackBusway™.
USA TrackBusway™ SYSTEM :
This plug-in busway system supports powertaps at multiple voltages, with customizable plug-ends to fit a variety of configurations.
Scalable Overhead Power:
A USA TrackBusway™ can be thought of like a power highway, designed to efficiently get power all across a facility, while allowing for easy expansions.
Plug-In Busway I up to 600V
1-Pole tap-offs connect one hot and the neutral to deliver 120 V (line-to-neutral).
2-Pole tap-offs connect two hots and no neutral to deliver 208 V single-phase or 240 V (line-to-line).
4-Pole tap-offs engage all three hots and the neutral to support 208 V or 480 V three-phase, four-wire configurations.
Three-Phase Tap-Off Wiring Diagram
Compatible with 120 V, 208 V, or 480 V Power
- Supports three-phase, four-wire configurations with line-to-line voltages up to 480 V.
- Ideal for powering equipment in warehouses, assembly lines, and production areas.
- Plug-in tap-offs can be repositioned without re-wiring or permitting.
- Optional isolated-ground tap-offs available for sensitive loads.
Technical Resources & BIM Tools
Access Revit families, IES files, PDFs, CAD models, and 3D assets for every USA TrackBusway product.
Select a resource type or product family to download files instantly.
Featured Videos
Track Busway System | Flexible Overhead Power for Open Ceilings
See how Track Busway’s continuous access slot enables precise placement of power drops and lighting—exactly where you need them. This video covers pre-wired task lighting, plug-and-play PowerDrops, and modular fittings designed to adapt as your workspace evolves.
From circuit switching to system expansion, USA TrackBusway™ delivers future-ready, plug-in overhead power without compromise.
Applications
